Custom Factory Wastewater Treatment Solid-liquid Separation Filter Press Chamber Filter Press

Product descriptions from the supplier

Products Description

Chamber Filter Press

The Filter Press is a kind of the solid-liquid separation machinery.It has been widely used in industrial production for many years.It has a good solid-liquid separation effect and wide suitability,especially for separation of fine and sticky materials.It has its special advantages.
When the mixed liquid flows through the filter cloth,the solid will be trapped on the filter cloth and accumulated to form into the cake.The clean liquid,which has not included the solid, will permeate from the filter cloth and be discharged from the taps on the plates or from the pipes on the 4 corners.

Specification

Model	Plate Size (mm)	Filtration Area (m2)	Qty of Plate (PCS)	Weight (KG)
XAMY4/450-30	450X450	4	9	830
XAMY8/450-30		8	19	920
XAMY10/450-30		10	24	9800
XAMY12/450-30		12	29	1010
XAMY16/450-30		16	36	1120
XAMY15/630-U	630X630	15	18	1710
XAMY20/630-U		20	24	1960
XAMY30/630-U		30	37	2315
XAMY40/630-U		40	49	2588
XAMY30/870-30	870X870	30	23	2380
XAMY40/870-30		40	30	2725
XAMY50/870-30		50	80	3118
XAMY60/870-30		60	46	3512
XAMY80/870-30		80	62	4261
XAMY50/1000-30	1000X1000	50	28	3960
XAMY60/1000-30		60	34	4510
XAMY70/1000-30		70	46	4968
XAMY100/1000-30		100	57	5685
XAMY120/1000-30		120	69	6320



Company Profile

Shanghai Junyi Filter Equipment Co., Ltd. specializes in the manufacturing and sales of filter equipment. We have professional and experienced technical team, production team and sales team, provide good service before and after sales. Adhering to the modern management mode, we always make the precision manufacturing, explore new opportunity and make the innovation.

After years of hard exploration, we has established a complete and effective service system and built an experienced service team, which not only provides customers with site planning and drawing of the layout and flow chart, but also can send our technical personnel to the site to guide the installation and commission for our customers.



We have a very strict and complete quality control system, which promises that goods we produced are always of the best quality, the enough inspectors to ensure that each product can meet the quality requirements of customers. We always final Inspection before shipment.

We produce more than 200 different models of the filter. The main products are the Press Filter / Bag Filter Housing / Automatic self cleaning filter / Basket filter / Magnetic filter / Candle filter / Leaf filter / Cartridge filter housing / Filter Plate / Filter Cloth/ Filter Cartridge /Filter Bag, also matched tanks, conveyors, etc. These equipment are widely used for the solid-liquid separation process in the industrial of mineral processing, petroleum, chemical industry, dyestuff, metallurgy, food, coal and carbon, inorganic salts, alcohol, light industry, textiles, environmental protection, energy and so on.

Packing & Shipping

FAQ

Q: Are you manufacturer?

A: Yes. We are experienced manufacturer of filter equipment.



Q:What products you provide?

A: We produce more than 200 different models of the filter. The main products are the Press Filter/Bag Filter Housing/Automatic self cleaning filter/Basket filter/Magnetic filter/ Candle filter/Leaf filter/Cartridge filter housing/Filter Plate/Filter Cloth/ Filter Cartridge /Filter Bag, also matched tanks, conveyors, etc.

Q: How to select the type you needed?

A: We will ask you some information: solid liquid kind, usage, flow rate, solid content
percentage, working temperature & pressure, etc. We have professional technical team which will work together with our sales to help you choose the suitable machine for you.



Q.Is it easy to operate for the new user ?

A: Yes. We offer you manual book and operating video. When you have any questions during using, we will answer you within 24 hours. For large projects, we can also send our engineers to your site for commissioning and training.



Q: What's MOQ?

A: 1 PCS.



Q: Do you accept OEM?

A: Yes.



Q:What's the payment terms ?

A: T/T, Western Union, L/C , Alibaba trade order or others. Generally 50% in advance, 50% before shipping.



Q:Quality Warranty.

A:12 months after the installation and commission or 18 months after it has been delivered to the site of the customer.
